    Ruijia Hopper scale S type load cell 300kg suitable for electronic platform scales, hopper scales

    Ask Lasest Price
    Brand Name : Ruijia
    Certification : CE
    Price : USD 352~ 395/piece
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram, MoneyGram
    Supply Ability : 2000 Piece/Pieces per Month
    Delivery Time : Within 2Weeks
    • Product Details
    • Company Profile

    Ruijia Hopper scale S type load cell 300kg suitable for electronic platform scales, hopper scales

    Ruijia Hopper scale S type load cell 300kg suitable for electronic platform scales, hopper scales

    Feature

    Alloy steel structure; bellows hermetically sealed by laser, nickel plated, waterproof and anti-corrosion, suitable for multiform environments; suitable for electronic platform scales, hopper scales, and other electronic weighing devies.

    Dimension

    Ruijia Hopper scale S type load cell 300kg suitable for electronic platform scales, hopper scales

    Range (kg) A B C D M
    10--50 51 12.7 64 16.1 M8
    100--150 50.8 19 76.2 22.4 M10x1.5
    200--2000 50.8 19 76.2 22.4 M12x1.75

    Specification

    Specification:
    Range : 10kg,150kg, 200kg, 250kg, 300kg, 500kg, 1000kg, 2000kg
    Accuracy : C2 & C3 Temp. effect on span(%F.S/10): ±0.017& ±0.011
    Comprehensive error(%F.S) : ±0.03 & ±0.02 Temp. effect on zero(%F.S/10): ±0.023 & ±0.015
    Rated output(mv/v) : 2.0±0.004 Compensated temp. range( ) : -10~+40
    Creep(%F.S/30min) : ±0.024 & ±0.016 Use temp. range( ) : -20~+55
    Zero balance(%F.S) : ±1.0 Excitation voltage(V) : 9~12(DC)
    Input resistance(Ω) : 350±5 Safe overload (%F.S) : 150
    Output resistance(Ω) : 350±3 Ultimate overload (%F.S) : 200
    Insulation resistance(MΩ) : ≥5000(100VDC) Defend grade : IP66
    Application
    Ruijia Hopper scale S type load cell 300kg suitable for electronic platform scales, hopper scales

    Company Information

    Ruijia Hopper scale S type load cell 300kg suitable for electronic platform scales, hopper scales
    Xi'an Ruijia Measuring Instruments Co., Ltd. is a manufacturer of force sensors and related products, dedicated to providing high-quality solutions for various industries. With a commitment to innovation, reliability, and precision, we have established ourselves as a trusted partner for businesses worldwide.
    Founded in 2005, we have accumulated years of experience in the field of weighing technology, enabling us to deliver products tailored to our customers' needs. Our product range includes a comprehensive selection of load cells, weighing modules, controllers, systems, and software solutions. We offer a diverse array of weighing products suitable for industrial automation, logistics, transportation, healthcare, retail, and more.
    At Xi'an Ruijia Measuring Instruments Co., Ltd., we pride ourselves on our technological expertise and dedication to continuous improvement. Our team of skilled engineers is committed to developing innovative solutions that push the boundaries of weighing technology, ensuring our products meet the highest standards of performance and accuracy. We serve a global clientele, catering to diverse market sectors across the globe. Our products are utilized by businesses of all sizes, from small enterprises to multinational corporations, in both domestic and international markets.
    Quality is at the core of everything we do. We adhere to stringent quality control measures throughout the manufacturing process to ensure that our products meet or exceed industry standards. Our commitment to quality has earned us a reputation for reliability and excellence among our customers. Besides, customer satisfaction is our top priority. We offer comprehensive customer service and support, including technical consultation, pre-sales assistance, and after-sales service, to ensure a seamless experience for our clients.
    With a focus on innovation, quality, and customer satisfaction, Xi'an Ruijia Measuring Instruments Co., Ltd. is your trusted partner for all your weighing sensor needs. Contact us today!

    FAQ

    Q: What are the applications of single point load cell/parallel beam load cell?

    A: Platform scale, package scale, animal scale, sorting machine, beehive scale, etc.

    Q:What is the raw material?

    A: Aluminum alloy

    Q: What is the accuracy/precision?

    A: C2 0.03% and C3 0.02%

    Q: What is the wire meaning?

    A: 5 wires (Red: E+, Black: E-, Green: S+, White: S-, Other color: ground)

    Q: How to install?

    A: One side are fixed and the other side are forced.

    Q: What is the load range for single point load cell?

    A: 0.1-1000KG
