    Spoke Type Load Cell 50t High Precision Measuring Weight for Machine Hopper Scale Automatic Equipment Force Compression Sensor

    Ask Lasest Price
    Brand Name : RUIJIA
    Model Number : RJ
    Certification : CE
    Price : USD90/piece
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 1000 Piece/Pieces per Month
    Delivery Time : 5-8 Work days
    • Product Details
    • Company Profile

    Spoke Type Load Cell 50t High Precision Measuring Weight for Machine Hopper Scale Automatic Equipment Force Compression Sensor

    Spoke Type Load Cell 50t High Precision Measuring Weight for Machine Hopper Scale Automatic Equipment Force Compression Sensor

    Features:
    · High stability
    · Low structural height
    · High comprehensive accuracy
    · Stable anti-interference signal
    · Nickel-plated high-quality alloy steel
    · Widely used in weighing equipment such as electronic belt scales, packaging scales, filling scales, etc. As well as in the field of automation equipment and testing
    .

    CAPACITY T 0-50T
    Rated Output mV/V 2.0±0.05
    Zero Balance %F.S. ±1
    Non-linearity %F.S. 0.05
    Hysteresis %F.S. 0.05
    Non-Repeatability %F.S. 0.03
    Creep (30min) %F.S. 0.03
    Temp. Effect On Output %F.S./10ºC 0.03
    Temp. Effect On Zero %F.S./10ºC 0.03
    Response frequency Hz 1k
    Material 42CrMoA
    impedance Ω 700/1400
    Insulation MΩ/100V DC ≥5000
    Recommended Excitation V 5-15
    Operating Temp. Range ºC -20-80
    Safe Overload %R.C. 150
    Ultimate Overload %R.C. 200
    Cable Size m Φ5*3m/5m
    Cable ultimate tension N 98
    TEDS Optional

    Spoke Type Load Cell 50t High Precision Measuring Weight for Machine Hopper Scale Automatic Equipment Force Compression Sensor

    Spoke Type Load Cell 50t High Precision Measuring Weight for Machine Hopper Scale Automatic Equipment Force Compression Sensor

    Company Information

    Spoke Type Load Cell 50t High Precision Measuring Weight for Machine Hopper Scale Automatic Equipment Force Compression Sensor

    Ruijia is a technical service enterprise specializing in force measurement technology research, product R & D, production, sales and service. It is mainly engaged in micro force sensors, high-precision load cells, S-type sensors, cantilever sensors, multi-dimensional force sensors, tension sensors, transmitters R & D and production of control instruments and provide system engineering control solutions. The company has modern and spacious workshops, high-quality production and testing equipment, professional R & D team and perfect management system to provide reasonable and practical solutions for our customers. With years of understanding and understanding in the field of automation, the company has always adhered to the enterprise operation concept of "user first", built a professional team in the field of automation, and provided customers with stable quality products and pre-sales and after-sales technical services. We always adhere to the tenet of independent innovation, only good products and scientific management, and always adhere to providing perfect products and system solutions, which is highly respected in our field; Constantly change and provide customers with excellent value-added services.

    Our advantages
    1, Professional
    17+years industrial experience,Know your needs quickly
    2, Wide Product Variety
    include:encoders,sensors,couplings, and other instruments widely used in CNC machinery, textile machinery, steel rolling machinery, linear guide system, hydraulic system, lifting machinery,servo motor and so on
    3, High cost-performence
    we can also customize replacement to the same specifications as the brand you need
    4, Good service
    If you have any question,Welcome to feel free to contact
